Haddonstone 2″ x 2″ Mosaic

Colorbody Porcelain

Description

Elegance (by sheet) Experience the beauty of Haddonstone, a ColorBody porcelain series designed to capture the essence of limestone tile. Inspired by the organic appeal of Portland Stone, Haddonstone offers two distinct visuals: a refined vein-cut design in matte and satin finishes and a raw crosscut option for a more natural aesthetic. Both styles are enhanced with RevealSync3D technology, ensuring a realistic texture and visual depth. With an expansive 24×48 size, a durable 2CM paver, and coordinating mosaic tiles, Haddonstone provides endless indoor and outdoor design possibilities, all backed by StepWise technology for superior slip resistance.

Colors

Thickness

5/16″

Sheet Size

12″ x 12″
(30.48 cm x 30.48 cm)

Finish

Matte

Mosaic Shape

2 x 2 Crosscut
Mosaic Tile
(Mesh-mounted)

View the collection.

Application

USAGE TYPES:	Target DCOF Wet	Suitable
Dry & Level – Interior Floor	N/A	✓
Wet & Level – Interior Floor	≥ 0.42	✓*
Shower Floors – Standard Center Drain	≥ 0.42	✓**
Shower Floors – Linear Drain	≥ 0.42 (Mosaic) ≥ 0.60 (Floor)	✓✛ (Floor)
Exterior Floor Applications (including patios, pool decking & other wet areas with minimal footwear)	≥ 0.60 (Floor)	✓***
Ramps & Inclines	≥ 0.65
Walls/Backsplashes	N/A	✓
Countertops	N/A	✓
Pool Linings	N/A	✓**

Grout Joint Recommendation: Floor Tile: 1/8″ (3/16″ when multiple sizes are installed in a modular pattern, and/or when installing tile with a length 15″ or greater in a staggered brick-joint pattern; overlap should not exceed 33%.) Mosaic Tile: 1/8″
A DCOF value of ≥0.42 is the standard for tiles specified for level interior spaces expected to be walked upon when wet, as stated in ANSI A137.1-A326.3. APPLICATION NOTES: Floor tile and mosaic suitable for exterior applications (provided it is noted as suitable in the applications chart above) in freezing and non-freezing climates, when proper installation methods are followed. * Matte floor and mosaic tile only. Mosaic tile only. * Floor, paver, and mosaic tile with StepWise™ Technology only. ✛12 x 24 floor and mosaic tile with StepWise™ Technology only

Testing

Breaking Strength	Chemical Resistance C650	Water Absorption C373	Scratch Hardness MOHS	Shade Variation Rating
C648 > 275 lbf Floor/Mosaics C1505 ≥ 2,000 lbf Paver	Resistant	<0.5%	8.0 – Matte 6.0 – Satin 8.0 – Matte (Paver)	V3

Durability

Floor Surface Wear Resistance
1 Residential Bathrooms 3 All Residential / Light Commercial
2 All Residential Areas 4 All Residential / Commercial

Notes

Since there are variations in all fired ceramic and natural products, tile and trim supplied for your particular installation may not match samples. Final confirmation should be made from actual tiles and trim prior to installation. Manufactured in accordance with ANSI A137.1 standards.
Not for use on ramps. Water, oil, grease, improper drainage and certain footwear can create slippery conditions. Floor applications expected to be exposed to these conditions require extra caution in product selection.
To achieve optimal results, all tile should be selected from multiple cartons and shading and graphic arrangement planned prior to installation.
Special consideration needs to be given when installing tiles greater than 15 inches. Please refer to daltile.com/LargeTiles for more information.

Manufacturer Advisory: All tile is measured by the DCOF AcuTest™ method. Tiles with DCOF values <0.42 are not recommended for use in areas with wet or slippery conditions.

Special care should be taken when grouting with dark pigmented colors. A grout release is recommended to prevent finely powdered pigments from lodging in the pores of the surface. Use of a latex modified thin-set is recommended for installation.
